The OPPO A9 PCAM10 is a mid-range MediaTek phone built around the Helio P70, a 6.53-inch FHD+ display, a 4020mAh battery, and Android 9 at launch, so most firmware problems on this model are tied to boot loops, failed updates, lock removal attempts, or repair work after the wrong package was used. This file set is especially tricky because it mixes normal dated archives with SP Flash Tool scatter builds, converted global packages, and a UFI dump, which means users should not treat every file here as the same type of firmware.
Download Firmware for OPPO A9
The files below are arranged from the newest dated builds to the oldest, with undated converted and specialist service packages listed afterward. Builds marked SCATTER are the clearest choice for MediaTek service flashing, while converted and UFI packages should be treated as advanced-repair material rather than routine updates.
Complete Device & Firmware Overview
- Device Name
- OPPO A9.
- Primary Model in This Set
PCAM10, with several packages also labeled forPCAT10.- Device Class
- Mid-range smartphone rather than a flagship, which matters because many users flash it to restore stability, battery behavior, or everyday usability instead of chasing major feature changes.
- Chipset
- MediaTek Helio P70 / MT6771 family.
- CPU / GPU
- Octa-core CPU with Mali-G72 graphics.
- Display
- 6.53-inch FHD+ class panel with 1080 x 2340 resolution.
- Battery
- 4020mAh.
- Launch Software Baseline
- Android 9 / ColorOS 6.
- Later Update Path
- OPPO A9 later received a stable Android 10-based update, which is why many later service packages for this model are treated as post-launch maintenance branches.
- Variant Notes
- Service sources commonly group PCAM10 and PCAT10 together under the China A9 firmware family.
- Firmware Types in This Package Set
- Standard archives, explicit SP Flash Tool scatter packages, converted global/F11-based service files, and one UFI full userpart dump.
- Flash Method
- Use SP Flash Tool for packages explicitly marked
SCATTER; for plain ZIP or RAR archives, extract first and confirm the internal format before choosing any tool. - Bootloader / Auth Reality
- Because this is a MediaTek OPPO service-flashing workflow, authentication or BROM-related hurdles can appear in SP Flash Tool on PCAM10 repair jobs.
- Build Range in This Set
- From A.09 and A.11 through C.15/C.31/C.43 and up to F.07/F.11.
- Release Window Represented Here
- From 2019-06-26 to 2022-07-23, plus several undated converted service packages.
- File Size Range
- 1.85GB to 6.66GB.
- Required Tools
- At minimum, a reliable USB cable, MediaTek USB drivers, archive extractor, and SP Flash Tool for the scatter builds.
- Security Patch Level
- Not stated in the supplied filenames, so it should be checked after extraction or after the device boots.
CRUCIAL WARNING: These packages are for the OPPO A9 firmware family built around PCAM10 and, in several cases, PCAT10; they should not be treated as universal OPPO A9 files because this set also includes converted builds tied to CPH1969EX, which is associated with the OPPO F11 Pro rather than a plain stock PCAM10 target.
Files marked SCATTER belong to a MediaTek SP Flash Tool workflow, while the UFI dump is specialist service material; flashing either one casually, or mixing a converted F11/global package into the wrong repair job, can turn a software issue into a deeper board-level recovery case.
Preparation Before Flashing
Open the preparation checklist
- Confirm the label and board identity first, because this page mixes
PCAM10,PCAT10, and converted packages that do not belong to the same risk level. - Back up everything you still can, especially on a working device, because service flashing on MediaTek phones is often used only after normal recovery has already failed.
- If the filename includes
SCATTER, prepare SP Flash Tool and MediaTek drivers instead of guessing with an OTA-style method. - Extract every plain ZIP or RAR first and inspect the contents; do not assume a non-scatter archive is ready for direct flashing.
- Avoid the converted global and F11-based files unless you are intentionally handling a conversion case, because those are not the safest first-line restore choice for a normal OPPO A9 repair.
- Reserve the
UFIdump for bench-level service work, not regular home flashing.
Quick Firmware Flash Instructions
- Match the phone to the right family first: use normal PCAM10 / PCAT10 builds for stock repair, and avoid converted
CPH1969EXor F11 files unless that exact conversion path is intentional. - For plain archives such as A.11, C.43, or F.11, extract the file fully and inspect the contents before doing anything else; if the extracted folder contains a MediaTek scatter file, move to the SP Flash Tool route.
- For every package already labeled
SCATTER, load the scatter file in SP Flash Tool and prepare for the usual MediaTek driver and authorization hurdles seen on OPPO repair jobs. - Treat
PCAM10_CONVERTED_GLOBAL...,...CONVERTED_TO_F11..., and theUFIdump as advanced-repair files only, not routine update packages. - After flashing, test boot stability, camera, fingerprint, charging, and network behavior before restoring personal data, because this model is often repaired with mixed service packages rather than one simple official consumer updater.
For the explicit scatter files on this page, use the full step-by-step SP Flash Tool guide. If an extracted package turns out to be a standard local-update archive rather than a scatter build, use the OTA / Sideload / Local Update guide only after verifying that format.
Frequently Asked Questions (FAQs)
Are PCAM10 and PCAT10 part of the same OPPO A9 firmware family?
In this package set, several filenames pair PCAM10 and PCAT10 together, and service sources also group them under the China A9 firmware family. That does not mean every file is interchangeable without checking the exact device first, but it does explain why many repair archives mention both model codes in one package name.
Which files are the safest starting point for a normal OPPO A9 repair?
The least confusing starting choices are the dated non-converted archives such as F.11, F.07, C.43, or A.11, because they look like regular branch builds rather than service conversions or chip-level dumps. Files explicitly labeled converted global, F11, or UFI should be left for cases where a normal stock-style restore is no longer enough.
What makes the _SCATTER packages different from the regular RAR and ZIP files?
Scatter packages are meant for MediaTek flashing workflows, and service guides for the OPPO A9 PCAM10 point directly to SP Flash Tool and scatter loading for this type of firmware. That makes them more predictable for technician repair work than a plain archive whose internal format has not been checked yet.
What is the risk with the converted global and converted-to-F11 files?
Those packages are not plain stock PCAM10 archives. One service listing explicitly ties these conversions to global or CPH1969EX bases, and CPH1969 is associated with the OPPO F11 Pro, so they should be treated as cross-model service conversions. That is why they are a poor first choice when the goal is simple stock restoration.
Did the OPPO A9 PCAM10 start on Android 9 and later move to Android 10?
Yes. The OPPO A9 launched on Android 9 / ColorOS 6, and later reporting shows a stable Android 10-based update for Oppo A9 and the related F11 series. That helps explain why this file set spans early A-series builds and later C/F maintenance branches.
Can flashing newer firmware make the OPPO A9 better for gaming?
Firmware can help if the current system is corrupted, unstable, or bloated, but it will not change the basic hardware ceiling of the Helio P70 platform. On this model, flashing is more useful for restoring smooth daily performance than for turning it into a much faster gaming phone.
Should I use the UFI dump like a normal firmware package?
No. A full userpart UFI dump is specialist repair material and is not the right entry point for everyday flashing, especially when regular archives or scatter packages are still available.
