Crucial Warning: Confirm your phone model is 1605-A01 (QK1605) before flashing. Never flash CPB files from other 360 series devices such as the 360 N5S (1607-A01) or 360 N6, as their partition offsets and display drivers differ and will prevent the device from booting.
Download Firmware for 360 N5
360_N5_(1605-A01)_7.0.049.PX.170823.QK1605.CPB
Official factory CPB container package running 360 OS 3.0 build 170823. Tested clean stock archive. MD5: d6d44c33362d07947ed2e00378c59809.
⬇️ Download via Google DriveQIKU 360_N5_(1605-A01)_6.0.121.P2.170809.QK1605.CPB
Official factory CPB package running stable 360 OS 2.0 build 170809. Recommended for returning to stock Android 6.0.1. MD5: 90ed0ab66a132e6184348cc41838dba9.
⬇️ Download via Google DriveFlashing Overview for 360 N5
- Download and install Coolpad / 360 YGDP Tool and Qualcomm USB drivers on your Windows computer
- Launch YGDP Tool and enter default password 369 or 963 when prompted
- Click "Assembly" and load the 360 N5 (.CPB) file into the tool
- Click "Apply" and wait for YGDP to unpack the CPB images
- Power off the phone, hold Volume Up, connect USB cable, and click "Start" in YGDP to flash
Expand preparation checklist for 360 N5
- Verify your phone model number is 1605-A01 under Settings -> About Phone or on the rear label.
- Install Qualcomm USB drivers and Coolpad YGDP Tool on a Windows PC.
- Ensure your phone battery is charged to at least 50%.
- Use a stable microUSB data cable connected directly to a rear USB port.
- Back up all personal files, photos, and accounts, as full CPB flashing formats user data.
Compatibility & Bootloader Notes
YGDP flashing communicates with the Qualcomm programmer inside the CPB archive over EDL or Fastboot mode. Unlocking the user bootloader is not necessary when servicing a stock device with YGDP.
Ready to Flash This Firmware?
Full step-by-step instructions for 360 N5, including prerequisites, error fixes, and screenshots, are on FlashGuideHub's YGDP Tool (Coolpad/360) guide.
Can also be flashed via QFIL: Open QFIL Guide →
Frequently Asked Questions
The 360 N5 carries model number 1605-A01 and motherboard codename QK1605. It is powered by Qualcomm Snapdragon 653 (MSM8976 Pro). Firmware filenames for this device explicitly include the QK1605 and 1605-A01 tags.
The .CPB file is a factory image container used by Coolpad and QiKU/360. Inside the container are Qualcomm partition headers, raw program XML files, baseband modem configurations, and raw ext4 partition images for system, cache, and userdata.
Yes. Flashing via YGDP writes complete factory partitions including boot and system. Because YGDP performs a full re-partition and erase, downgrading between these official CPB builds restores the earlier 360 OS 2.0 environment cleanly.
When YGDP Tool opens its login dialogue, the default password is standard factory assembly code 369 (or 963 on older builds). Entering 369 grants full access to the assembly flashing interface.
