ZTE Axon 11 SE 5G (9000N) Firmware Flash File Download [Stock Rom]
The ZTE Axon 11 SE 5G (model 9000N) is a powerful mid-range smartphone from ZTE’s premium Axon series, featuring the MediaTek Dimensity 800 5G chipset. This model was released for the Chinese domestic market. For users needing to unbrick their device, resolve deep-seated software errors, or revert to the original factory software, flashing the official stock firmware is the ultimate solution.
Important Note: This is the official firmware for the Chinese model (9000N), which does not include Google Play Services (Play Store) by default. Furthermore, the MediaTek Dimensity 800 5G chipset has Secure Boot. Flashing this device requires a special procedure using an authentication bypass tool in conjunction with SP Flash Tool. Proceed with caution.
Quick Device Specs
- Device: ZTE Axon 11 SE 5G (9000N)
- Release year: 2020
- Chipset: MediaTek Dimensity 800 5G (MT6873)
- Display: 6.53″ LTPS IPS LCD, 2340×1080
- Battery: 4000 mAh (Non-removable)
- Memory: 6GB/8GB RAM + 128GB/256GB storage
- Camera: 48MP + 8MP + 2MP + 2MP quad rear, 16MP front
- OS: Android 10 with MiFavor UI
- Region: China (No Google Play Services)
Required Downloads
| File / Tool | Download Link |
|---|---|
| SP Flash Tool | Download Tool |
| MediaTek USB VCOM Drivers | Download Drivers |
| MTK Auth Bypass Tool | Download Bypass Tool |
Stock ROM & Firmware
| Version | Android | Region | Type | Download | Size |
|---|---|---|---|---|---|
| V1.0.0B16MR2 | 10 | China | SP Flash Tool | Download | ~3.5 GB |
How to Flash (Requires Auth Bypass)
- Install Drivers: Download, extract, and install the MediaTek VCOM drivers. You may need to disable Driver Signature Enforcement on modern Windows versions.
- Extract All Files: Unzip the downloaded Firmware, the SP Flash Tool, and the MTK Auth Bypass Tool into separate, easy-to-access folders.
- Run the Auth Bypass Tool: Open the MTK Auth Bypass tool folder and run the executable file. Click the “Disable Auth” or “Bypass” button.
- Connect the Phone for Bypass: Power off your Axon 11 SE completely. Press and hold both the Volume Up + Volume Down buttons, then connect the phone to your PC via USB-C cable. The bypass tool should detect the phone and display a success message like “Protection Disabled.” Do not close the bypass tool or disconnect the phone.
- Launch SP Flash Tool: While the phone is connected and bypassed, open flash_tool.exe.
- Load Scatter File: In SP Flash Tool, click “choose” next to “Scatter-loading File” and select the MT6873_Android_scatter.txt from the firmware folder.
- Set Mode and Flash: Ensure the mode is set to “Download Only”. Click the large green “Download” button. The flashing process should begin immediately.
- Wait for Completion: The flash is complete when a window with a large green checkmark appears in SP Flash Tool.
- Finish: You can now close both the SP Flash Tool and the Auth Bypass tool, disconnect your phone, and hold the Power button to turn it on. The first boot will be slow.
FAQs
Q1. Why is an “Auth Bypass Tool” necessary for this phone?
Modern MediaTek chipsets like the Dimensity 800 have a security feature called Secure Boot (or SLA/DAA) that prevents unauthorized software flashing. The Auth Bypass Tool temporarily disables this protection, creating a window where SP Flash Tool can communicate with the device and write the firmware.
Q2. Can I use this firmware to install Google Play Store?
No. This is the official stock firmware for the Chinese market, and it does not include Google Mobile Services (GMS), which are required for the Play Store and other Google apps. You would need to attempt to install GMS manually after flashing, which can be a complex and often unreliable process.
Q3. Will this firmware work on the global version of the ZTE Axon 11?
Absolutely not. This firmware is specifically for the Axon 11 SE 5G (9000N) which uses a MediaTek Dimensity chipset. The global Axon 11 models use different hardware (e.g., Qualcomm Snapdragon chipsets). Flashing this firmware on the wrong model will permanently damage it.
Q4. What if the Auth Bypass tool does not detect my phone?
This usually points to a driver issue. Ensure the VCOM drivers are correctly installed. The phone must be fully powered off, and you must press and hold both volume buttons before connecting the USB cable. Using a different USB port can also help.
Troubleshooting (ZTE Axon 11 SE)
- SP Flash Tool gives a red error bar or authentication error: This is the classic sign that Secure Boot is still active. You either did not use the Auth Bypass tool, or the bypass was not successful. You must repeat the bypass procedure.
- Phone is completely dead (bricked) after a failed flash: Flashing modern protected devices carries a higher risk. If a flash fails and corrupts the preloader, the device may not be detectable even by the bypass tool. This often requires advanced “test point” methods to fix and should be handled by a professional.
- Phone boots into the Chinese language: During the initial setup wizard, look for the language selection option (usually the first screen, look for the word 语言 or a globe icon) to switch to English or another language.
- No 5G service outside of China: The modem and antenna configuration in the Chinese 9000N model is optimized for Chinese 5G network bands. While you may get 4G/LTE service in other countries, 5G connectivity is not guaranteed.
